Inconel 625 Flanges

Deep Steel Center Inconel 600 and Alloy 625 are non-magnetic materials. The main focus of this alloy is its corrosion resistance. Not only is UNS N06600 Alloy 625 Flange resistant to oxidation, but this nickel-based alloy also performs well at high temperatures. In fact, its properties do not change over a wide temperature range. Inconel 625 weld neck flanges have high tensile strength and toughness from cryogenic temperatures to 2000°F. This property of the alloy is mainly due to the solid solution strengthening effect. Material No. 2.4816, Alloy 625 For solid solution strengthening of blind flanges, this material uses a high-melting-point metal such as columbium or molybdenum and is reinforced with a nickel-chromium matrix. Nickel-based ASTM B564 Inconel 625 slip-on flanges offer excellent fatigue resistance. Also, like most Inconel alloys, this material is resistant to stress corrosion and cracking caused by chloride ions. The main users of Alloy 625 forged flanges include industries such as shipping and the petroleum industry. Additional benefits of using Inconel 625 flanges include high fracture toughness and processability.

Inconel 625 Flanges Manufacturers, Inconel 625 Flanges Suppliers, Inconel 625 Flanges Stockists, Inconel 625 Flanges Exporters

Inconel 625 Flanges Manufacturers in India, Inconel 625 Flanges Suppliers in India, Inconel 625 Flanges Stockists in India, Inconel 625 Flanges Exporters in India

Inconel 625 flanges are manufactures from a corrosion-resistant and strong nickel-chromium alloy containing 58% nickel, 20% chromium, carbon, manganese, silicon, sulfur, copper, and iron. Navstar Steel is a leading supplier and manufacturer of Inconel 625 flanges in a variety of scales and types. The flange material has an extremely high tensile strength of 930 MPa and a minimum yield strength of 517 MPa. This strong material also has a melting point of 1350 °C. This allows the flange to be used even in demanding applications.

ANSI B16.5 Inconel 625 Flanges Specification

Dimensions : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings

Standards : ASTM, ASME Flanges, ANSI Flanges, DIN Flanges, EN Flanges, BS Flanges etc.

Specifications : ASTM B564 / ASME SB 564

Size : 1 / 2” to 36″

Class : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.

Grade : Inconel 625 – UNS N06625

Our Inconel 625 Flanges conforms to NACE MR0175/ISO 15156

Inconel 625 Flanges Manufacturers in Mumbai, Inconel 625 Flanges Suppliers in Mumbai, Inconel 625 Flanges Stockists in Mumbai, Inconel 625 Flanges Exporters in Mumbai

ASTM B564 Inconel 625 Flanges Equivalent Grades

STANDARD

WERKSTOFF NR.

UNS

GOST

AFNOR

JIS

BS

EN

OR

Inconel 625

2.4856

N06625

ХН75МБТЮ

NC22DNB4M

NCF 625

NA 21

NiCr22Mo9Nb

ЭИ602

Inconel Alloy 625 Flanges Chemical Composition

Grade

Ni

Cr

Fe

C

Mn

Si

Mo

Co

Al

Ti

Nb + Ta

P

S

Inconel 625

58.0 min

20.0 – 23.0

5.0 max

0.10 max

0.50 max

0.50 max

8.0 – 10.0

1.0 max

0.40 max

0.40 max

3.15 – 4.15

0.015 max

0.015 max

625 Inconel Alloy Pipe Flanges Mechanical Properties

Density

Melting Point

Tensile Strength

Yield Strength (0.2%Offset)

Elongation

8.4 g/cm3

1350 °C (2460 °F)

Psi – 135,000 , MPa – 930

Psi – 75,000 , MPa – 517

42.5 %

Types Of Available Products AISI, ASTM, DIN, ASME Inconel 625 Flanges

Inconel Alloy 625 Flanges
625 Inconel Blind Flanges
ASTM B564 Inconel 625 Slip On Flanges
Inconel UNS N06625 Pipe Flanges
ASTM B564 Inconel 625 BLRF Flanges Manufacturer
B564 Inconel 625 Weld Neck Flanges Manufacturer
ASME SB564 Inconel 625 RTJ Flanges Stockiest
Inconel 625 Threaded Flanges Distributors
Inconel 625 Alloy SWRF Flanges
Top Quality Inconel 625 Socket weld Flanges
625 Alloy Inconel Orifice Flanges Exporter
ASTM B564 Inconel 625 DIN Flanges
ASTM/ASME Inconel Alloy 625 Forged Flanges
625 Inconel Ring Type Joint Flanges Stockiest in India
Inconel Alloy 625 Reducing Flanges
ASTM B564 Inconel 625 Lap Joint Flanges
Inconel WERKSTOFF NR. 2.4856 Long Weld Neck Flanges
Inconel 625 Alloy Screwed Flanges Dealers
ASTM B564 Alloy Inconel 625 SORF Flanges
Inconel 625 Plate Flanges Stockholder
625 Inconel Alloy WNRF Flanges Suppliers
B564 Inconel 625 Spectacle Blinds Flanges Suppliers
ASME SB 564 Inconel 625 Flanges
AISI Inconel 625 ASTM B564 Flanges
ASTM B564 Inconel 625 Alloy Loose Flanges
Inconel 625 Flange JIS Standard Flanges
